Straight Line Boring Machine >> SPEED 212 NC Construction System Boring Machine

SPECIFICATIONS:
MODEL SPPED 212

No. of spindle per Italian boring head

21 ＋ 21

Clamp

4

Distance between centers

32 mm

Table size

 1200 x 560 mm

Max. boring depth

25mm ( Calculated with a blade length of 70mm）

Spindle Motor

4 HP + 4 HP

Servo Motor

750w + 750w (付煞車)
Machine size (mm) 1800 x 1500 x 1780 mm
With variable-frequency Drive 5HP x 2 PCS
Automatic chip removal function of vertical

* Specifications subject to change without prior notice
