>> HS-207 Super Surface Planer
|
|
|
FEATURES:
 The brilliant design is basically developed from the conventional hand planer its powerful feeding system enlarges the efficiency and steadiness of the surface
planning works.- More advanced features including: Easily insery-in cutter set, quick loading, easy knife adjusting convenient maintenance.
- One end opening design enables the planning jobs of the wuder workpieces.
High griping ability of reinforced rubber feeding belt. Also easy to adjust its tension and rotating track.
Feeding beut speed adjustable.
|
|
|
| MODEL |
HS-207 |
Table Area |
32
1/2" x 13 3/4" (825 x 345mm) |
Maximum
Planning Width |
12"(305mm) |
Maximum
Planning Thickness |
51/2"(140mm) |
Knives Setting Angle |
150 |
Back knife Size |
121/2"
x 23/4" x 11/16"(312 x 70 x 18mm) |
Front knife Size |
121/4"
x 215/16" x 11/16"(312 x 75 x 18mm) |
Feeding Speed (FPM) |
198(60Hz),
165(50Hz) |
Motor |
1P, 2HP 3P, 3HP |
Net Weight |
880 Ibs(400kg) |
Gross Weight |
1000
lbs(455kg) |
| Shipping Size |
42"
x 34" x 48"(1067 x 863 x 1220mm) |
|
* Specifications
subject to change without prior notice |
|
